Awesome People Lab · Print 001
A little
desk dock.
A free 3D print for people who want a little bit of Awesome People on their desk.
It holds five Gridfinity bins behind the sign. It is not a product. We just thought it would be fun to make something useful with our logo.
- From Awesome People Lab
- Print 001
- Dock
- Gridfinity 5 × 1
- Materials
- 1–6
- For
- Your desk
Interactive model
Take a look. Then make one.
Pick a finish, spin it around, and download the same multicolor 3MF used in the viewer. The print files stay available if the 3D studio cannot load.
A little order
Five Gridfinity slots hide behind the sign.
One small project
The base, sign, supports, and logo relief print as one piece.
Pick your finish
Light and dark universal 3MF files come first; presets are optional.
A small lab thing
Not everything has to be an app.
This is a small, physical thing for people who like Awesome People Software. Print it, put it to work, give it to a friend, or just enjoy the idea that we made it.
The five slots use the open-source Gridfinity storage system, so the dock works with bins and accessories people already print and use.
- Support-free upright orientation
- Full-width 220 mm logo panel
- Five 42 mm Gridfinity slots
Print profile
If you want to print it.
Start with the universal 3MF: it has six named material assignments but no printer, feeder, or filament-vendor binding. Map all six for the full logo, reuse loaded filaments for a four-channel unit, or assign every part to one loaded filament for a single-material, recessed-logo version.
With four channels, use white, blue, orange, and green for the light finish; use black, white, orange, and green for the dark finish. The slicer can assign more than one logo part to the same loaded filament.
Body
Navy / white
Orange
Green
Teal
Blue
- Finished size
- 220 × 60 × 62.71 mm
- Layer profile
- 0.16 mm standard
- Structure
- 3 walls · 15% gyroid
- Gridfinity pitch
- 42 mm nominal
Gridfinity fit varies by printer and material. Test a normal 1 × 1 module before committing to the full print, and adjust XY compensation if your profile runs tight. A Bambu H2D/two-AMS preset remains available in the viewer for convenience; it is not required to print the dock.
